Uses and Classes

Linear drainage refers to systems that drain along their entire length, rather than at one particular point, as a gully does. Most are variations on the theme of an enclosed channel, typically with a u-shaped cross-section and some form of grating over the top.

There is an enormous range available, from simple half-metre or metre-long polymer concrete units for private driveways to stainless steel units for medical or food preparation areas to combined kerb and drainage systems such as the 'Beany Block' manufactured by Marshalls.

Idealised Linear drain
Idealised Linear Drain
 Classes of Linear drain
Classes of Linear Drain
They come in a range of sizes, from 50mm deep units for roof drainage to 250mm deep motorway drains, and in a ever widening range of materials, including polymer concrete, wet-press concrete, HDPE, and stainless steel. The end use of the drain will determine which type is most suitable to a specific application.
There are 6 'grades' available which comply to the European Standard DIN 19580 (there is no equivalent BS) and these are shown in the table above. Note that the overall class rating of a linear drain is dependent on both channel and grating meeting the above test loads.
There are two basic types - those with built-in falls and those that maintain a regular depth along their entire length, and so must be laid to a fall. The units with the built-in falls tend to be used to drain large, flat areas, such as car parks, freight yards, airports etc, and the 'regular depth' type are used for short lengths of drain, and on areas with a natual slope or fall. Two types of Linear Drain
Two basic types of Linear Drain

ruler

Calculating Requirements

There is a standard equation used to calculate the linear drain requirements, based on rainfall rates (r mm/hr), and the size of area being drained (A m²). The run-off capacity (Q) is measured in litres per second and is calculated thus....

Q = (A x r)/3600

In the UK, we typically use a rainfall intensity rate (r) of 75mm per hour, so for a 120m² pavement......

Q = (120 x 75)/3600 = 2.5 litres per second

This indicates that a linear drain for the small p[rohject under consideration here must have a flow capacity of at least 2.5l/s, which is well within the cpabilities of most systems. Some of the larger commercial systems are capable of handling flows of 200-1,000 litres per second or more.

However, the brain work isn't finished yet. The flow capacity of any given linear drain can be calculated by another equation, which makes allowances for the dimensions of the channel, the roughness of the material and the gradient. This equation is beyond the scope of these pages, and it is usually not required as the manufacturers supply full technical support for their products, and have tables and graphs that can be used to find the right drain and gradient for any given run-off capacity requirement. If you have a pavement of 250m² or more, we would suggest you contact one of the manufacturers listed on the links pages for further information.

For smaller jobs, such as the 120m² pavement used in the example above, it can usually be assumed that a standard 100mm deep channel has run-off capacity of around 4-5 l/s even at relatively shallow gradients such as 1 in 300, and so are suitable for most pavements of 200m² or less.

For domestic paving projects, these 'off-the-shelf' units, readily available from Builders' Merchants for less than £20 per metre are ideal for use at the thresholds of garages, or for areas where you want to wash the car, van, boat or whatever. One note of warning, however; the types of 'bargain' linear drain obtainable from DIY chains tend to have cheap, thin, crappy gratings supplied with them. Your local builders' merchant will be able to supply a linear drain with a heavy duty grating to Class B, as given in the table above. Driveway Linear Drain
Domestic Driveway Use

ruler

  spacer

Jointing

Linear drains are sectional and therefore there is a joint between adjacent units. Many types incorporate some form of overlap joint, so that lengths of drain have a distinct 'male' and female' end, usually a tongue and groove arrangement. These joints can be left 'dry' in most small-scale applications, as they will seal with silt and debris over time, but they should be sealed with a suitable silicon or polysulphide sealant where water-tightness is an issue.
Tongue/Groove jointing
Overlap Jointing
Bitumen Jointing
Bitumen jointing compound being applied
Other systems, usually the heavy duty, bigger drains, rely on polysulphide, silicon or bituminuous sealant between adjacent units to form a water-tight joint, and this method of jointing is also used where a section of drain is cut to fit, thereby losing the 'overlap' joint capability. In certain, specialised applications, such a chemical handling areas or food preparation areas, continuous or jointless drains may be custom manufactured to meet the requirements of a specific project.

ruler

Connecting to Sewer System

Obviously, the linear drain has to discharge somewhere, and this section looks at a few of the more common methods used to connect the linear drain with the surface water sewer system.
Bottom outlet on linear drain
Bottom Outlet
On small domestic application, the linear drain is normally connected to the main drainage via a pipe union end cap or a bottom outlet section. Both these methods enable the drain to be converted from a linear drain to a standard, circular sewer pipe which is buried undergound and connected to the SW system, as described on the laying drainage page. Pipe Union End Cap
Pipe Union End Cap
Outfall Box
Outfall Box
On larger projects, special outfall units and silt boxes are available to suit each manufacturers range. These are designed to cope with the heaviest of flows, and to connect to various sizes and types of drainage. It is beyond the scope of these pages to detail the vast range of silt boxes, mud traps, grease traps and other fittings available in each range and we suggest you contact the manufacturers listed on the links page.
Some linear channels have simple 'knock-out' holes at the base of each section that can be removed by tapping with a hammer (as shown opposite) or by sawing, to enable easy connection to a sub-surface pipe. In the example below, a Clark-Drain 400 channel is connected to a 100mm uPVC pipe via a trapped fitting. Although the trapped fitting isn't essential when fitting to a SW system, it was used in this case to eliminate any problems with smells and sewer gases emanating from the drains.

Once attached to the pipe, the channel is laid on a bed of concrete and tapped down to the required level.

bottom outlet removal
trapped connection
A trapped connection to the drainage system
channel connected
Linear channel is connected to trap
Click here for a fully detailed guide to installing an Aco Drive Drain linear system to a residential driveway.

ruler

Accessories and Fittings

Schematic mitred angle
Mitred Angle
As we have seen, connecting these linear drains in one straight line is relatively straightforward and simple, but what about curves, corners, angles and junctions? Many of the systems available now offer standard 90° corner units and also 90° T-junction units. Some ranges include radius units for laying to specified arcs, or offer custom manufactured angles. If your project involves a number of these fittings, you should consult with the manufacturers to identify what fittings are available in the various ranges on the market.
On some projects, it is acceptable to mitre any such angles by cutting the channel unit with a power saw. It is important that the adjacent ends of both channels meeting at the angle are cut to the angle of mitre to ensure the channel width is maintained and a 'snag' is not introduced into the channel. The resulting joint should be sealed with a suitable sealant, such as Polysulphide or silicone rubber to maintain water-tightness. Plan view of mitre
Plan View of Mitred Angle

ruler

Gratings

Just as there is a wide choice of channels to suit virtually every situation, so there is a bewildering array of gratings to use with them. They are manufactured in a range of materials including cast iron, ductile iron, galvanised steel, stainless steel, pre-stressed concrete and composite resins. There is an ever-expanding range of finishes, too, including brass, galvanised, coloured composite, and even custom gratings to match particular paving schemes or floor-coverings. They generally come in lengths to suit the accompanying channel, usually 500mm or 1000mm, but there are 'half-gratings' also available, which require two such gratings to each unit of channel.
Linear drain gratings
A selection of Gratings
The gratings are strength-rated in the same way as the channels (see Table 1 above) and so a Class C Channel should have at least a Class C grating. Putting a lower rated grating on a channel, eg, a Class B grating on a Class D Channel, gives the finished unit the lower strength rating, ie, in our example, the finished drain would have a B rating, despite the channel being rated as D.
There are 2 basic grating types - slotted and mesh, and the choice between the two is determined by end use. The slots and mesh sizes vary from relatively wide 20mm 'gaps' for use on highways, to 4.5mm 'gaps' that offer protection against trapping heels on ladies' shoes, and a host of sizes in between. There are also specialist gratings for applications such as athletic tracks, industrial areas and combined kerb/drainage systems.

Some slotted systems have a single slot running longitudinally along the the channel, rather than the more usual transverse slot. These are usually reserved for special applications, such as liquid containment areas or washdown areas.

Most gratings are held firmly in place by some form of locking system. This prevents their being lost, stolen or vandalised, while still allowing access for cleaning and maintenance. The most common locking system is some form of locking bar that slides into a recess within the channel, and then uses a bolt to fix the grating to the locking bar. There are typically two such locking bars to each grating. Locking bar
Locking Bar for Gratings

ruler

Construction

The construction method is generally identical for most forms of linear drainage. They need to be laid on a C25 concrete bed at least 100mm thick, and then haunched according to the type of paving being used. Alternatively, they can be laid on a 12-40mm mortar bed over a prepared concrete race.
spacer In Block Paving
Construction in Blockwork
Three constructions are shown opposite, which cover most of the usual paving types; note that the thickness of the bedding concrete may need to be increased for Clases D, E and F, depending on site conditions and end use.

Note also that the channel and grating sit 3-5mm below the level of the paving, to ensure water can find its way into the drain.

spacer In Bitmac Surfacing
Construction in bitmac
The channels are laid onto the prepared bed and tapped down to level using a small paviors' mall or rubber hammer. Once all the channels are laid, they are haunched to prevent them moving, then connected to the surface water system via one of the methods shown above, and finally, the gratings are fitted. spacer In Concrete Slab
Construction in Slab
Linear drain
'Economy' linear drain laid to a patio
The photograph opposite illustrates a typical Class A linear drain being used on a patio. It has been laid on a concrete bed, and haunched to both sides. A thin, galvanised grating suitable only for foot traffic (Class A) is shown in position atop the channel unit, along with the locking bar.

Its position, at the edge of a pavement close to a brick wall, means that it will not be subjected to much in the way of foot traffic, and so this is probably the correct type of channel and grating for this location. The 50mm gap between the channel and the wall will need to be patched in, probably with an unsightly mortar, whereas laying the channel tight against the wall would have resulted in a much neater looking finish. Just why it wasn't laid tight against the brickwork in the first place is a mystery!

spacer

ruler

spacer

Detailing within a block pavement

Where a linear drain runs through a block paved area, the paving should be brought up right to the edge of the channel, as shown above, rather than allow a 'fillet' of concrete or mortar to be used between the paving and the channel. In many cases, a soldier course is used to add detail around the linear drain, and this may be laid in the same block or in a contrasting colour, as suits the scheme. Alternatively, the blockwork pattern can be maintained right up to the the edge of the channel.
cutting-in around linear drain
Cutting-in suggestions for linear drains with block paving.
